8.7 Using the DTM (with FDT)
Rotork’s DTM is downloadable via http://www.rotork.com/document/index/versions/masterID/55353/
Rotork does not supply a Comm DTM nor does it supply an FDT. These must be purchased from
another vendor.
This approach enables the major TB parameters to be configured.
Fig 8.5: Setting the control mode and discrete block control
