8.6 Default settings
Transducer Block
Param. No.
Description
Range
Default Setting
50
Limited Range
Position Minimum
0-100%
0%
51
Limited Range
Position Maximum
0-100%
100%
52
Deadband
0.0-25.5%
5.0%
53
Hysteresis
0.0-25.5%
2.0%
54
Slow Mode Range
0-100%
5%
55
Motion Inhibit Time
0-255s
5 sec
56
Action on Loss of
Comms
Value:
0 – No Action
1 – Open
3 – Close
5 – Stop
7 – Position
Any other value = off
0 (No action)
57
Comms Lost
Position
0-100%
0%
58
Comms Fault Timer
0-255s
10 sec
59
Aux Input Mask
0x00-0xFF
0F
60
ESD HW_DI-4/Net
Disable
0- ESD function
1- Network disable
0
61
Part stroke % travel
position
0-100%
90%
62
Part stroke limit
0 – Close limit
1 – Open limit
1
63
Part stroke timeout
0-7200 seconds
300 sec
64
Partial stroke status
2 Date fields:
Partial Stroke Success
Partial stroke Failure
(MM/DD/YY HH:MM:SS)
01/01/72 00:00:00
65
Control Mode [DO
4 function]
Value:
0 – Positioning mode
1 – ESD
2 – S5 relay operate
3 – Partial stroke (DO)
4 – AO only
5 – Two-wire control
6 – Positioning mode
0
Note:
1. Not all actuator types
support partial stroking.
2. Mode 6 offers both
position control and
partial stroking in multibit
support..
66
Discrete Block
control
Bit:
0 – Multiple support
1 – Single support
0
