Setting Up The FF CP Card
Publication PUB089-005-00_0618 83 of 116
8.4.1 Analogue Only control
Uses AO block only – no discrete control permitted.
Transducer Block Settings
Set between 0-25.5% (typically 5%)
Set between 0-25.5% (typically 2%)
Param. 55 – Motion Inhibit Timer
Set between 0-255 seconds (typically 3 sec)
Analogue Output Block Settings
Must be set to PV for BKCal_Out
Note:
If the control mode parameter is modified, the TB must be set to OOS prior to the modification
for the changes to be accepted. Once accepted, the Transducer Block must be returned to
Auto.
8.4.2 Discrete Only control
Uses one or more DO blocks – no AO position (%) control permitted. The support available from the
DCS will determine how many blocks are required. Where DCS Boolean Fan-In functions are
available, multiple support mode can be chosen but, if this option is chosen, only one DO block can be
used.
Multiple Bit Support
Systems using the multiple state of a single DO block, with only one DO block selected for use.
(Unused DO blocks must be left OOS). Only one DO block may be used if this mode is
selected. The block selected will depend on the actual discrete control functions required. In
most cases DO 1 or DO 2 will be the most useful.
Transducer Block Settings
Set either 0,1,2,3,5 or 6 if this block, DO 4, is used
Param. 66 – Discrete Block Control
Set Multiple to use Boolean Fan In and one DO block.
Single Bit Support
Systems using only bit 0 from each DO block and using up to four DO blocks to obtain discrete
control.
Only the first bit, i.e. bit 0, may be used from each DO block in this mode.
Transducer Block Settings
Set either 0,1,2,3,5 or 6 if this block, DO 4, is used
Param. 66 – Discrete Block Control
Set Single to use only values of 0/1 in all DO blocks.
Note:
If either the DO4 control mode and / or discrete block control are modified, the TB must be set
to OOS prior to the modification for the changes to be accepted. Once accepted, the
Transducer Block must be returned to Auto.
