rotork Mk3 - Resource Block

Foundation Fieldbus CP Option Card Technical Manual
44 of 116 Publication PUB089-005-00_0618
6.1 Resource Block
Every Fieldbus device includes a resource block that describes to the host controller the system
resources the device needs. This block contains data that is specific to the FF CP card itself. There
are no links to this block and there is no function schematic. All the standard Resource Block
parameters are included, with the addition of read only data shown in the following table that is
specific to the FF CP card.
Index
Parameter
Description
Units
Class
1
ITK_VER
ITK version tested to
None
RO
2
SW_REV
Firmware revision of FIC
None
RO
3
MB_REV
Main or Interface board firmware revision
None
RO
4
DEVICE_STATUS1
Special device status parameters
None
RO
5
DEVICE_STATUS2
Special device status parameters
None
RO
6
DEVICE_STATUS3
Special device status parameters
None
RO
7
DEVICE_STATUS4
Special device status parameters
None
RO
8
DEVICE_STATUS5
Special device status parameters
None
RO
9
ACT_DEVICE_STATUS
Special device status parameters
None
RO
Indexes 1 to 3 contain information for ITK test and Rotork firmware version control.
Indexes 4 to 9 give information on the current status of the various function blocks and the actuator
control interface as shown below.
Index 4: DEVICE_STATUS1
Bit
Title
Description
0
Simulate enable jumper on
The Simulation enable switch is ON
1
2
3
4
RB in OOS mode
The Resource block is OOS
5
6
7
8
EEPROM failure
The EEPROM has failed on the FIC
9
10
11
12
