2015-2017 5.0L Mustang Phase 1/2 RHD ROUSHcharger Kit
SECTION A – DISASSEMBLY
1316-RHD-AA 12152016 9 800.59.ROUSH
5. Remove the tie down battery clamp.
6. Remove the battery.
7. Remove the battery tray by rst removing the
three (3) 8 mm head bolts.
8. Release the eight (8) pushpin retainers by pulling
the center pin and remove the radiator trim cover.
STOP
STOP
Before continuing, refer to the CALKIT found
on our website under product ID 421823.
Determine the PCM fl ash method you will be
using. If performing the PCM fl ash yourself or
at a preferred ROUSH dealer, proceed to step
12. If sending the PCM to ROUSH for a ROUSH
performed PCM fl ash, continue with step 9.
To Next Page
