2015-2017 5.0L Mustang Phase 1/2 RHD ROUSHcharger Kit
SECTION A – DISASSEMBLY
1316-RHD-AA 12152016 21 800.59.ROUSH
45. Remove the line from retainer near the front of the
RH cylinder head.
46. Remove the six (6) intake manifold mounting
bolts.
47. Lift the intake manifold and fuel rail assembly
straight up and pull it forward to access the
harness connectors at the rear. Disconnect the
CMCV harness connector. Cut the retaining clip
to remove the harness. Use care – Do not cut
the harness. Disconnect the four (4) harness
connectors. Release/remove the two (2) pushpins.
Connector
To Next Page
