Sound System Setup NiteHAWK Internet Jukebox

3-4 22022602

Table 3-2 - Extension Speaker Worksheet

Sheet 2

4-Ohm Speakers Connected To Transformer Taps E1 through E6

Place the quantity of speakers in the blank under QTY and multiply the quantity times the

power consumption. Place your results in the blank under

TOTAL.

4-Ohm Speakers connected to channel 1 transformer taps.

Connections Qty Total

Speakers for the 1-watt taps: (E1 to E2) ____ at 1 watt each = ____watts

Speakers for the 4-watt taps: (E1 to E3) ____ at 4 watts each = ____watts

Speakers for the 16-watt taps: (E1 to E4) ____ at 16 watts each = ____watts

Speakers for the 36-watt taps: (E3 to E5) ____ at 36 watts each = ____watts

Speakers for the 49-watt taps: (E2 to E5) ____ at 49 watts each = ____watts

Speakers for the 64-watt taps: (E1 to E5) ____ at 64 watts each = ____watts

Speakers for the 100-watt taps: (E3 to E6) ____ at 100 watts each = ____watts

Speakers for the 121-watt taps: (E2 to E6) ____ at 121 watts each = ____watts

4-Ohm Speakers connected to channel 2 transformer taps.
