NiteHAWK Internet Jukebox Parts Catalog
22022602 8-17
4 CHANNEL PREAMPLIFIER
Refer to Figure 8-8.
Ref. Part No. Description Qty
40982601 4 Channel Preamplifier Assembly ........................................................................... Ref.
1 40982701 Cover - Preamplifier ..................................................................................................... 1
2 61195201 CBA – 4 Channel Preamplifier ..................................................................................... 1
3 80713008 #8-32 x 1/2 SEMS Hex WRHS .................................................................................... 5
Figure 8-8 - 4 Channel Preamplifier
2
3
1
