Rowe NiteHAWK - SHELL ASSEMBLY (Internal View, Right Hand Side)

NiteHAWK Internet Jukebox Parts Catalog
22022602 8-13
SHELL ASSEMBLY (Internal View, Right Hand Side)
Refer to Figure 8-5.
Ref Part No. Description Qty
1 61182102 Panel - Cabinet Back ................................................................................................... 1
2 70134146 Bolt – 1/2 x 13 x 1.25 Carriage .................................................................................... 1
92400061 Nut 1/2-13 Type 7 (Not Shown) ................................................................................... 1
3 34007701 Bezel - Reject Button ................................................................................................... 1
34007601 Button - Reject ............................................................................................................. 1
4 70163215 Cylinder Lock ............................................................................................................... 1
21947501 Washer - Indexing........................................................................................................ 1
21425601 Lockbolt ....................................................................................................................... 1
5 30781702 Cup - Slug (Black)........................................................................................................ 1
21792901 Door - Slug Cup ........................................................................................................... 1
21793001 Bracket - Slug Cup ...................................................................................................... 1
6 40966901 Skid Rail ....................................................................................................................... 2
7 40966301 Bracket - Cabinet Corner ............................................................................................ 4
8 21572601 Cable – Fall Stop ......................................................................................................... 1
