NiteHAWK Internet Jukebox Parts Catalog
22022602 8-15
CORE COMPUTER ASSEMBLY – Exploded View
Refer to Figure 8-6.
Ref. Part No. Description Qty
61176505 Computer Assembly (Low Profile) ........................................................................... Ref.
1 70134502 Thumbscrew ................................................................................................................ 1
2 34090101 Clamp – Disc Drive ...................................................................................................... 1
3 40957301 Housing – Disk Drive ................................................................................................... 1
4 40972701 Cover Plate - PCI ......................................................................................................... 1
5 40952202 Power Supply FLEX ATX SFF ..................................................................................... 1
6 34074201 Clamp – Power Supply ................................................................................................ 2
7 61188401 Cover - Core Computer ............................................................................................... 1
8 40959901 I/O Core Plate .............................................................................................................. 1
9 34075301 Plate - ATX Reset Board ............................................................................................. 1
10 34052402 CBA - Power ON/RESET/LEDs ................................................................................... 1
11 21889250 Hardware - DB9/DB15 ................................................................................................. 2
12 61175803 Housing – Core Computer ........................................................................................... 1
13 22216402 Fan ............................................................................................................................... 1
14 34089001 Plate – Fan Interface ................................................................................................... 1
15 22183102 Gasket – Computer Fan .............................................................................................. 1
16 40924208 Single Board Computer, 2.8 GHz ................................................................................ 1
•26731501 Heatsink & CPU Fan Replacement Kit (See Note 1) .................................................. 1
17 22120602 Modem – Internal - Low Profile .................................................................................... 1
18 34072101 Bracket – Core Mounting ............................................................................................. 2
19 34072201 Cover – PCI Low Profile .............................................................................................. 3
20 70093403 Clamp – Cable, 1” ........................................................................................................ 1
Not Shown:
22132246 Cable Assembly RIB (Com 2 to DB9).......................................................................... 1
22132247 Cable Assembly DR RIB ON/RESET ........................................................................... 1
Note 1:
For either 61176503 or 61176505 Assemblies. Installation of this kit should not
be attempted on location.
To Next Page
