Rowe NiteHAWK - DOOR ASSEMBLY (External View)

NiteHAWK Internet Jukebox Parts Catalog
22022602 8-5
DOOR ASSEMBLY (External View)
Refer to Figure 8-1.
Ref. Part No. Description Qty
61181201 Door Assembly - Front (Blue) ............................................................................... Ref.
61181202 Door Assembly - Front (Green) ............................................................................. Ref.
61181203 Door Assembly - Front (Red) ................................................................................ Ref.
1 61180403 Corner-Cap Silver Paint Pattern (Used on 61181201) ............................................. 1
61180404 Corner-Cap Gold Paint Pattern (Used on 61181202/03) .......................................... 1
2 40963901 Bezel - Front Door (Upper - Blu) (Used on 61181201) ............................................. 1
40963902 Bezel - Front Door (Upper - Green) (Used on 61181202) ........................................ 1
40963903 Bezel - Front Door (Upper - Black) (Used on 61181203) ......................................... 1
3 22301101 Applique - Front Door (Silver) (Used on 61181201) ................................................. 1
22301102 Applique - Front Door (Gold) (Used on 61181202 & 61181203) .............................. 1
4 61180303 Bezel – Monitor Silver Paint Pattern (Used on 61181201) ....................................... 1
61180304 Bezel – Monitor Gold Paint Pattern (Used on 61181202/03) ................................... 1
5 40964301 Cover - Light (Vertical) .............................................................................................. 2
6 61180503 Corner-Cap Silver Paint Pattern (Used on 61181201) ............................................. 1
61180504 Corner-Cap Gold Paint Pattern (Used on 61181202/03) .......................................... 1
7 40964201 Cover - Light (Horizontal) .......................................................................................... 2
8 61180201 Bezel - Front (Lower - Blu) (Used on 61181201) ...................................................... 1
61180202 Bezel - Front (Lower - Green) (Used on 61181202) ................................................. 1
61180203 Bezel - Front (Lower - Black (Used on 61181203) ................................................... 1
9 34084701 Block-out - Card Reader ........................................................................................... 1
34085801 Label - Card Reader Blockout ................................................................................... 1
10 22135609 MEI
®
Bill Acceptor with 1000 Bill Stacker .................................................................. 1
or 22135611 Coinco
®
Vantage
®
Bill Acceptor with 1100 Bill Stacker ............................................. 1
11 40964801 Applique - Front Door (Silver) (Used on 61181201) ................................................. 1
40964802 Applique - Front Door (Gold) (Used on 61181202 & 61181203) .............................. 1
12 40964703 Extrusion Vertical (Silver) (Used on 61181201) ........................................................ 2
40964702 Extrusion Vertical (Gold) (Used on 61181202 & 61181203) .................................... 2
13 40963801 Inlet - Coin ................................................................................................................. 1
14 61180701 Graphics - Front (Blu) (Used on 61181201) ............................................................. 1
61180702 Graphics - Front (Green) (Used on 61181202) ......................................................... 1
61180703 Graphics - Front (Red) (Used on 61181203) ............................................................ 1
61180801 Panel Front (Outer) ................................................................................................... 1
61180802 Panel Front (Inner) .................................................................................................... 1
15 40964603 Extrusion Horizontal (Silver) (Used on 61181201) ................................................... 2
40964602 Extrusion Horizontal (Gold) (Used on 61181202 & 61181203) ................................ 2
Items Not Shown:
34084801 Blockout – Bill Acceptor ............................................................................................. 1
