NiteHAWK Internet Jukebox Sound System Setup

22022602 3-5

Table 3-3 - Extension Speaker Worksheet

Sheet 3

8-OHM Speakers Connected To Transformer Taps E1 through E6

Place the quantity of speakers in the blank under QTY and multiply the quantity times the

power consumption. Place your results in the blank under

TOTAL.

8-Ohm Speakers connected to channel 1 transformer taps

Connections Qty Total

Speakers for the .5-watt taps: (E1 to E2) ____at .5 watt each = ____watts

Speakers for the 2-watt taps: (E1 to E3) ____at 2 watts each = ____watts

Speakers for the 8-watt taps: (E1 to E4) ____at 8 watts each = ____watts

Speakers for the 18-watt taps: (E3 to E5) ____at 18 watts each = ____watts

Speakers for the 24-watt taps: (E2 to E5) ____at 24 watts each = ____watts

Speakers for the 32-watt taps: (E1 to E5) ____at 32 watts each = ____watts

Speakers for the 50-watt taps: (E3 to E6) ____at 50 watts each = ____watts

Speakers for the 72-watt taps: (E1 to E6) ____at 72 watts each = ____watts

Speakers for the 95-watt taps: (E3 to E7) ____at 95 watt each = ____watts

8-Ohm Speakers connected to channel 2 transformer taps
