Rowe NiteHAWK - Hanger Bracket Assembly; Figure 8-11 - Hanger Bracket Assembly

Parts Catalog NiteHAWK Internet Jukebox
8-20 22022602
HANGER BRACKET ASSEMBLY
Refer to Figure 8-11.
Ref. Part No. Description Qty
61114003 Hanger Bracket Assembly ........................................................................................ Ref
1 87843700 #10-24 Hex Keps Nut ................................................................................................... 4
2 34015401 Standoff - Hanger ......................................................................................................... 4
3 61114103 Hanger - Weld Assembly ............................................................................................. 1
4 89973724 #10-24 x 1 1/2 Carriage Bolt ........................................................................................ 4
1
2
3
4
Figure 8-11 - Hanger Bracket Assembly
