Maintenance and cleaning work must only be carried out if the engine has been turned off and the spark plug
connector has been removed.
Pos: 4.7.12 /I nne nteil/Si cher heits vorsch rif ten/W artung und Lag erung /Kerze ns tecke r niem als bei la ufen de m Mot or a bzie hen @ 13\ mod_1280219056956_1521.doc @ 110075
• Never remove the spark plug connector when the motor is running! Risk: Electric shock.
Pos: 4.7.13 /I nne nteil/Si cher heits vorsch rif ten/W artung und Lag erung /Tank n ur i m Fr eie n en tle ere n @ 0 \mod_1115186486750_1521.doc @ 1649
• If the tank has to be emptied, this should be done in the open, and with a cold engine. Take care to ensure that no fuel
is spilt.
Pos: 4.7.14 /I nne nteil/Si cher heits vorsch rif ten/W artung und Lag eru ng/N ur O rig inal ersa tzt eil e ver w end en S ABO @ 0 \mod_1115186601093_1521. doc @ 1642
For warranty and safety reasons, original replacement parts must be used at all times.
Pos: 5. 1 /---------- 1 Leer zei le ---------- @ 0\mod_1114611787140_1521.doc @ 2070
Pos: 5. 2 /Inne nteil/ Besch reib ung der B auteil e/1 BE SCHR EIBUN G DER BAU TEI LE @ 0\mod_1115187892468_1521.doc @ 1664
6 DESCRIPTION OF COMPONENTS
Pos: 5.3 /Inne nteil /Bes chrei bung d er Bauteil e/Bes chr eibung der Bau teile 52- S A @ 22\ mod_1359556284751_1521.doc @ 168397
1 Safety control bracket for the engine brake
2 Handlebar-upper part
3 Bar screws
4 Handlebar-lower part
5 Oil-refill neck with measuring rod
6 Engine cover
7 Exhaust protection grid
8 Ignition plug
9 Cutting height adjuster
10 Deflector
11 Air filter
12 Rear driving wheels
13 Belt drive covers
14 Tank cap
15 Starter cable grip
16 Drive control bracket
Pos: 6. 1 /---------- 1 Leer zei le ---------- @ 0\mod_1114611787140_1521.doc @ 2070
Pos: 6. 2 /In nent eil /Vor ber ei ten de Ar beit e n/1 VOR BER EIT ENDE AR BEIT EN @ 0\ mod_1115194917734_1521.doc @ 1672
7 PREPARATION
Pos: 6. 3 /In nent eil /Vor ber ei ten de Ar beit e n/Vor ber eite nde Ar beit en T e xt 52- S @ 15\ mod_1302699952233_1521.doc @ 127130
The following unit parts are included in the package for mower assembly:
• Mower
• Handlebar-lower part
• Handlebar-upper part
• Bar support
• Ejection flap
• Tool bag with the following content:
• Operating instructions with Declaration of Conformity
• Guarantee card and guarantee conditions
• Diverse fastening parts.
Should any part be missing, please contact your professional dealership.
Pos: 6. 4 /In nent eil /Vor ber ei ten de Ar beit e n/1. 1 H olma bst ützung a nba uen ( Ab bil dung B ) @ 15\ mod_1302700266608_1521.doc @ 127146
Attach bar support (Illustration B )
Pos: 6. 5 /In nent eil /Vor ber ei ten de Ar beit e n/Hol ma bst ützu ng a nba uen T e xt @ 6\mod_1186403846453_1521.doc @ 38120
– Position the handle support on the two preassembled screws between the rear wheels.
– Tighten by hand with a curved washer and a hexagon heat nut.
Pos: 6. 6 /In nent eil /Vor ber ei ten de Ar beit e n/1. 1 F ührung s holm- Unt erteil anbau en (A bbi ld ung B ) @ 15 \mod_1302700745872_1521.doc @ 127162
Attach handlebar-lower part (Illustration B )
Pos: 6. 7 /In nent eil /Vor ber ei ten de Ar beit e n/Führ ung s holm-U nt ertei l anb aue n Te xt 5 2-S @ 15\mod_1302701086615_1521.doc @ 127178
– Insert an M 8 hex nut into each of the two cams on the mower housing in front the rear wheels.
– Attach the outer parts of the two bar ends to the cams.
– Place a washer and then a spacer on each of the two fastening hex screws.
– Fix the two screws into the cams through the bar ends.
