Converting the machine to side ejection (Illustration R3 )
Pos: 11.22 /In nent eil/M ähbetr ieb/U mbau al s Seite naus wurf mäher T ext @ 13\mod_1280318421567_1521.doc @ 110379
– Stop the engine and remove the spark plug.
– Remove the cover plate (1) from the right-hand side of the housing.
To do this loosen the two self-locking nuts (2) and pull the washers (3) off, pull the two flat round screws (4) out from the
inside (cutting space) and remove the cover plate.
The mulching blade system does not have to be converted!
For the equipment to be used as a mulching machine again, the cover plate (1) must be replaced. To do this, insert the cover
plate into the housing from the inside in such a way that the two bore holes in the cover plate are aligned with the bore holes
in the housing. Insert the two flat round screws (4) into the bore holes from the inside (cutting space), put the washers (3) in
place and tighten using the two self-locking nuts (2).
WARNING
Never use the equipment with the deflector damaged or missing.
Always work with the deflector closed (folded downwards) even when the machine has been converted for
mulching.
Pos: 12 .1 /---------- 1 Le erzei le ---------- @ 0\ mod_1114611787140_1521.doc @ 2070
Pos: 12 .2 /I nne nt eil/ Wart ungsi nt er vall e/1 WARTU N GSIN TE RVA LLE @ 4\ mod_1159190053844_1521.doc @ 20987
14 SERVICE INTERVALS
Pos: 12 .3 /I nne nt eil/ Wart ungsi nt er vall e/War tu ngsi nter va lle Wic htig @ 1 9\mod_1346242607856_1521.doc @ 148773
IMPORTANT
Avoid damage! Under extreme or unusual conditions, shorter servicing intervals than the ones specified below may
be necessary. If you establish any problems, please contact an authorised workshop.
Pos: 12 .4 /I nne nt eil/ Wart ungsi nt er vall e/War tu ngsi nter va lle T e xt @ 19\mod_1346242427863_1521.doc @ 147976
Carry out routine servicing on the machine in line with the following servicing intervals.
Work must be carried out at the following servicing intervals in addition to the maintenance work listed in these operating
instructions.
Pos: 12 .5 /I nne nt eil/ Wartung sint ervall e/Vor der erst en In betrieb nahm e Benzi ner @ 19\ mod_1346243924408_1521.doc @ 149049
Before initial use
• Check the oil level Y1 .
• Check all screw connections for a tight fit.
• Check the cutting blade screw and have an authorised workshop tighten it if necessary.
• Check whether the safety control bar for the engine brake is working perfectly.
• Check that all protective devices have been attached properly and are not damaged.
Pos: 12.6 /Inn ent eil/War tungsi nter vall e/Vor j edem Be trieb Be nzin er Seite naus wurf @ 21 \mod_1351075225220_1521.doc @ 161597
Before every operation
• Check the lawn area and remove any objects.
• Check the area of the boundary wires (if an auto mower is being used for lawn care).
• Check the oil level Y1 .
• Check the condition and firm fit of the blade, if necessary have an authorised workshop tighten the blade screw.
• Check whether the safety control bar for the engine brake is working perfectly.
• Check that all protective devices have been attached properly and are not damaged.
Pos: 12.7 /Inn ent eil/War tungsi nter vall e/All e 10 Betrie bsst unde n Seite nausw urf @ 22\ mod_1353325454469_1521.doc @ 165545
Every 10 operating hours
• Check all screw connections for a tight fit.
• Check the blade coupling regularly for wear and a tight fit.
Pos: 12 .8 /I nne nt eil/ Wart ungsi nt er vall e/N ach j ede m B etri eb @ 19 \mod_1346243106654_1521.doc @ 148981
After every operation
• Clean the mower.
• Check the blade for damage and wear.
Pos: 12 .9 /I nne nt eil/ Wart ungsi nt er vall e/Ei nfa hrzei t – Nac h den erst en 5 Betri ebsst und en B&S @ 1 9\mod_1346244491464_1521.doc @ 149253
Running-in time – after the first 5 operating hours
• Change the engine oil Y1 .
Pos: 12.10 /In nent eil/W artung sinter vall e/All e 25 Betr iebsst und en oder al le drei M onate L uftfi lter, Z ünd kerze rei nige n @ 22\mod_1353577712696_1521.doc @ 166804
Every 25 operating hours or every three months
• Clean the air filter paper insert W .
• Clean the spark plug and adjust electrode distance Y .
Pos : 12.11 /Innenteil/Wartungsintervalle/Alle 50 B etrie bsst u nde n od er ei nm al pr o J ahr 54 er Ben zi ner @ 2 1\mod_1352883350775_1521.doc @ 164421
Every 50 operating hours or once a year
• Change the engine oil Y1 .
• Lubricate or grease the wheel bearings.
Pos: 12 .12 / Inn ent eil/ War tung sin ter vall e/B ei der J ahr esins pekti on Benzi ner, mit Antr ieb @ 19\ mod_1346244765719_1521.doc @ 149304
During annual servicing
• Have the air filter paper insert replaced W .
• Have the spark plug replaced Y .
• Clean the gearbox and the area under the belt cover.
• Check the drive throttle cable and adjust it if necessary.
