15 CARE AND SERVICING OF YOUR LAWNMOWER
Pos: 13 .3 /I nne nt eil/Si cher h eitsh in wei se/Si cher hei tsh in wei s: Le se n, M ess er, Stei n, M ot orst op, Heis s, Z ü ndker ze, H a ndsc huh e @ 0\mod_1115363145562_1521.doc @ 1532
Safety instruction!
See table for explanation of symbols page 3
Pos: 13 .4 /I nne nt eil/P fleg e u nd Wart ung des Mä hers/ 1. 1 R einig ung @ 4\mod_1161265862177_1521.doc @ 22593
Cleaning
Pos : 13.5 /Innenteil/Pflege und Wartung des Mähers/Reinigung Text Benzin vor ne hoc hkippen @ 10\mod _12 51376466503_1521.doc @ 89955
IMPORTANT
To clean the mower and for maintenance work do not place it on its side but tilt forwards O (spark plug upwards)
because otherwise there may be problems starting the engine. Secure the mower in the raised position!
Remove all dirt and grass directly after mowing. Use a brush or cloth to clean.
Do not rotate the cutter bar, as otherwise engine oil is pumped into the carburettor/air filter and there may be problems
starting the engine.
IMPORTANT
Never clean the drive area, engine parts (like ignition system, carburettor, etc.) seals and bearing points with high-
pressure cleaner or normal water jet. Damages or expensive repairs can be the result.
Pos: 13.6 /Inn ent eil/Pfl ege und Wartu ng des Mä hers/ 1.1 Aufb ewahr ung @ 0\ mod_1115363938281_1521.doc @ 1810
Storage
Pos: 13 .7 /I nne nt eil/P fleg e u nd Wart ung des Mä hers/ A ufbe wahr u ng Te xt @ 0\ mod_1115364661953_1521.doc @ 1824
Always keep the machine in a clean condition in a closed, dry room out of reach of children. Always allow the engine to cool
down before you store the machine in a closed room.
Pos: 13 .8 /I nne nt eil/P fleg e u nd Wart ung des Mä hers/ 1. 1 Tr ansp or t u nd Si cher ung d es Ger ät es @ 10\ mod_1250513367024_1521.doc @ 86523
Transporting and securing the equipment
Pos: 13 .9 /I nne nt eil/P fleg e u nd Wart ung des Mä hers/ Tr ansp ort u nd Sic her u ng Te xt 52-S @ 15\ mod_1301472986450_1521.doc @ 126219
– If the equipment has to be carried, do not hold the ejection flap! Hold the device at the front and behind on the cross
tube of the guide handlebar – top.
Please take the weight of the machine into consideration before lifting it (see Technical Data). Lifting large weights can
result in health problems.
We recommend that the device is always lifted or carried by two persons.
– Transport the equipment standing.
– Park the means of transport on level ground so that the device cannot roll away before it is secured
– Secure the device with approved load-strapping means (e.g. tie-down straps with clamping elements) on or inside the
vehicle. Tie-down straps are belt bands made of synthetic fibres. Every tie-down strap is designated. The label contains
important details for application.
– For loaded goods that can roll, we recommend using direct strapping with four belts. Secure the device at the wheels so
that it does not move during transportation.
ATTENTION
Do not tighten the belts too firmly. Fixing the equipment too firmly can cause damage.
Pos: 13 .10 / Inn ent eil/ Pfl ege und War tung de s M äher s/ 1.1 War tung des Mess er bal ken s @ 0\mod_1115365509765_1521.doc @ 1823
Maintenance of the blade
Pos: 13.11 /In nent eil/Pfl ege un d Wart ung des M ähers/ Wart ung des Mes serbal kens T ext Benzi n @ 19 \mod_1346246117815_1521.doc @ 149465
A sharp blade guarantees optimum cutting performance. Before you start mowing, always check the condition and firm
attachment of the cutting blade. The blade attachment screw must always be tightened by an authorised workshop. If the
blade screw is too tight or too loose, the blade coupling and cutter bar can become damaged or loose which can lead to
serious injuries. A worn or damaged blade must always be replaced.
Pos: 13 .12 / Inn ent eil/ Pfl ege und War tung de s M äher s/ 1.1 N ach schl eif en un d Aus wuc hten des M ess erbal ke ns ( Abbi ldu ng Q) @ 0\mod_1115365616312_1521.doc @ 1815
Sharpening and balancing the blade (Illustration Q )
Pos: 13 .13 / Inn ent eil/ Pfl ege und War tung de s M äher s/N ac hschl eif en u nd A us wuc hten des Mess er bal kens Hi nw eis Benzi n @ 0\ mod_1115618908515_1521.doc @ 1839
WARNING
The sharpening and balancing of the blade should be carried out only by an authorized specialist workshop. An
improperly sharpened or unbalanced blade can cause severe vibrations, and damage the lawnmower.
Pos: 13 .14 / Inn ent eil/ Pfl ege und War tung de s M äher s/N ac hschl eif en u nd A us wuc hten des Mess er bal kens n eu T ext @ 1 2\mo d_1257776115383_1521.doc @ 98647
The cutting edges of the cutting blade may be grinded only until the respective value (see Figure Q ) or the marking (1) on
the cutting blade (ring) has been reached. Attention! Observe the grinding angle of 30°.
Your professional workshop can check this value - (grinding limit) for you!
Pos: 13 .15 / Inn ent eil/ Pfl ege und War tung de s M äher s/N ac hschl eif enu nd A us wuch ten des Mess er bal kens Hi nw eis M arki eru ng @ 9 \mod_1228810807409_1521. doc @ 70873
WARNING
A blade by which the wear limit (marking) has been exceeded can break off and spin away; this can cause severe
injuries.
