Sabo 52-S A - Engine Maintenance and Storage; Engine Cleaning and Oil Change; Air Filter, Spark Plug, and Winter Storage

16
GB
IMPORTANT
Never use a pressure cleaner or ordinary water jet to clean the motor. Damages or expensive repairs can be the
consequence of such action.
Pos: 14 .7 /I nne nt eil/ Wart ung des Mot ors/ 1. 1 Öl wec hsel @ 0\mod_1115368583406_1521.doc @ 1867
Oil change
Pos: 14.8 /Inn ent eil/War tung d es Mot ors/Öl wechs el Hinw eis @ 6\mod_1199793171487_1521.doc @ 43497
NOTE
For environmental reasons, we recommend that the oil change is performed by an authorised workshop.
Pos: 14.9 /Inn ent eil/War tung d es Mot ors/Öl wechs el Gerä t kippen Text @ 0\ mod_1115368599984_1521.doc @ 1875
The first oil change of a new engine is necessary after 5 operating hours, and thereafter every 50 hours of operation or at
least once per mowing season.
– Before the engine or whole device is tipped to drain the oil off, empty the petrol tank and allow the engine to run until it
stops due to lack of fuel.
– Switch off the engine and disconnect the spark plug cable.
– Change the oil with the engine still warm.
– To change the oil, remove the dipstick from the filler and lay the mower on its side so that the used oil drains into the
catch tray.
Old oil should be disposed off in accordance with the relevant local regulations and on no account be
discharged into the sewerage system or into the ground.
– Turn the mower upright and pour high quality oil (for quantity and type, see technical data) into the filler. Screw on
dipstick and check oil (see Chapter Filling with oil, illustration Y1 )!
Pos: 14 .10 / Inn ent eil/ War tung de s Mo tors /1 .1 R ei nigen bz w. Austa usc h d es Luftfi lt ers ( Ab bild ung W ) @ 0 \mod_1115369153171_1521.doc @ 1868
Cleaning and replacing the air filter (Illustration W )
Pos : 14.11 /Innenteil/Wartung des Motors/Rei nigen bzw. Austausch des Luftfilters Text Motor SA26878, SAU11011, SA26879, SAU10191, SAU11035 @ 1\mod_1133358006115_1521.doc @ 6675
– Loosen the screw on the air filter cover and open the cover downwards.
– Carefully remove the filter insert (1) and tap out on a smooth surface or replace if very dirty.
– Never oil the insert or blow out with compressed air. Very dirty or oily filter inserts must be replaced.
– Replace in housing after cleaning or replacing of the filter element and carefully replace cover.
In the worst conditions (large amounts of dust) it is necessary to clean the mower whenever it has been used, otherwise
every 3 months or after 25 hours of operation.
(Order no. filter insert see original spare parts and accessories)
Pos : 14.12 /Innenteil/Wartung des Motors /1.1 Kontrolle der Zündkerze (Abbildung Y ) @ 0\mod_1115369306250_1521.doc @ 1865
Checking the spark plug (Illustration Y )
Pos: 14.13 /Innenteil/Wartung des Motors/Kontrolle der Zündkerze Text 0,7mm @ 0\mod_1115369340031_1521.doc @ 1873
To check for wear, remove the spark plug connector and unscrew the spark plug. If the electrode is badly worn the spark
plug must be replaced as a matter of course. (Order no. see original spare parts list and accessories).
Otherwise it is sufficient to clean the spark plug and set the electrode gap to 0.7 mm. Screw the spark plug (pay attention to
sealing ring) into the engine by hand and tighten using the socket wrench. Press on spark plug connector. Replace the spark
plug annually.
Pos: 14 .14 / Inn ent eil/ War tung de s Mo tors /1 .1 V orsch rif ts mäß iges „Ü ber wint ern“ des Mo tors ( oder l äng er er Ni cht ge brauc h) @ 0 \mod_1115369429437_1521.doc @ 1869
Correct winter storage of the engine (or when not used for a long period of time)
Pos: 14 .15 / Inn ent eil/ War tung de s Mo tors /V orsc hr ifts mäßi ges „Ü ber winter n“ des Mo tors G erät kip pen Te xt @ 0\mod_1115369463687_1521.doc @ 1878
– Empty the petrol tank or allow the engine to run until it stops due to lack of fuel.
– Switch off engine and disconnect spark plug cable.
– Drain off the oil while the engine is still warm. Fill with fresh oil (for quantity and type, see technical data).
– Clean grass and chaff from cylinder and cylinder head fins and around muffler.
– Always keep the machine in a clean condition in a closed, dry room out of reach of children.
Pos: 15 .1 /---------- 1 Le erzei le ---------- @ 0\ mod_1114611787140_1521.doc @ 2070
Pos: 15 .2 /I nne nt eil/S tör ungs ur sach en u nd deren Beseitigung/1 STÖRUNGSURSACHEN UND DER EN BESEITIGUNG @ 0\mod_1115373523343_1521.doc @ 1904
17 TROUBLESHOOTING
Pos: 15.3.1 /I nne nteil/St ör ungsur sach en und dere n Besei tig ung/St örung stab ellenel ement e/1 Ta bell enkopf @ 0\mod_1115374760156_1521.doc @ 1884
Fault
Possible cause
Remedy
Pos: 15.3.2 /I nne nteil/St ör ungsur sach en und dere n Besei tig ung/St örung stab ellenel ement e/M otor spr ingt nic ht an 52-S @ 1 5\mod_1300364283115_1521.doc @ 125917
Motor does not start up
Switch holder not turned down.
Press switch holder onto the upper part of
the bar D .
Fuel tank empty.
Refill with clean and fresh fuel.
Spark plug connector loose.
Push plug connector in place or have it
checked by an authorised workshop.
Spark plug defective or soiled or
electrodes worn out.
Replace or clean spark plug, set electrode
distance to 0.7 mm Y .
Too much petrol feed to motor (spark
plug wet).
Have it checked by an authorised
workshop.
Air filter soiled.
Clean or replace air filter insert W .
