2.5Technical Data - version M2+ and B2+
2
Size (w x h x d)280 x 470 x 481 mm
Weightapprox. 15 kg
Machine housing materialThermoplastic material
Power RatingSee the data plate
Supply VoltageSee the data plate
Power cord lengthapprox. 1,200 mm
Water mains connection3/4" Gas type
Water mains pressureSee the data plate
CapacityWater tank4.0 litres
Coffee grounds drawer30 grounds
Control panelFront panel
A-weighted sound pressure levelless than 70 dB
Pump pressureMax. 1.5 MPa (15.0 bar)
Water connections (for water NW version only)Maximum pressure0.8 MPa (8 bar)
Minimum pressure0.15 MPa (1.5 bar)
Operating conditionsMinimum temperature:
above 2°C
Maximum temperature:
less than 32°C
Maximum humidity:
less than 80%
Safety devicesBoiler pressure safety valve
Safety thermostat
222222
PRData plate for maximum water supply pressure
222
Subject to engineering and manufacturing changes due to technological improvements.
