English
15
92
Remove the 2 screws shown in figure using a Torx T10 screwdriver.
1515151515
Remove the boiler assembly and disconnect the wires and pipes.
1515151515
15.9Removing the Steam Boiler
15
The following tools are necessary to remove this component:
151515
Torx screwdriver T10 and T20
Long nose pliers
Pliers for Oetiker clamps (or pair of tongs)
151515
Toreachtheparttoreplace,followthedismantlingprocedureforthecoversthat
has been previously outlined.
1515
Remove the 2 screws shown in figure using a Torx T10 screwdriver.
1515151515
Remove the boiler assembly and disconnect the wires and pipes.
1515151515
