Saeco MAGIC M2 - Disassembling the Coffee Dos. Unit Coil and Micro; Disassembly Plate Supporting the Solenoid Valves Unit; Disassembly Solenoid Valve Unit for Recovery and Blowing Air; 15.16 Air Discharge Solenoid Valve Disassembly

English
15
95
15.13Disassembling the coffee dos. unit coil and
micro.
15
The following tools are necessary to remove this component:
1515
Torx screwdriver T10
151515
Disassembletheexternalcoversasdescribedabove,untildisassemblyoftheupper
cover, to access the component to be replaced.
15
Electrically disconnect the coil. Remove the coil from its hous.
15151515
Disconnect the microswitch wiring and remove it from its housing.
151515
15.14Disassembly plate supporting the solenoid valves
unit
15
The following tools are necessary to remove this component:
1515
Torx screwdriver T10 and T20
Long nose pliers
151515
Toreachtheparttoreplace,followthedismantlingprocedureforthecoversthat
has been previously outlined.
15
Disconnect the solenoid valve from the electrical power and hydraulic power. Remove
the brew group. Remove the 2 screws shown in figure using a Torx T10 screwdriver.
151515
15.15Disassembly solenoid valve unit for recovery and
blowing air
1515
The following tools are necessary to remove this component:
151515
Torx screwdriver T10 and T20
Long nose pliers
15151515
Toreachtheparttoreplace,followthedismantlingprocedureforthecoversthat
has been previously outlined.
151515
Disconnectthesolenoidvalvefromtheelectricalpowerandhydraulicpower.
Remove the 2 screws shown in figure using a Torx T20 screwdriver.
151515151515151515
15.16Air discharge solenoid valve disassembly
15
The following tools are necessary to remove this component:
151515
Torx screwdriver T10 and T20
Long nose pliers
151515
Toreachtheparttoreplace,followthedismantlingprocedureforthecoversthat
has been previously outlined.
1515
