15REMOVING COMPONENTS
15
Themachinedoesnothaveanysafety
device;electricalcomponentsand
componentsthatreachhightemperatures
arecontainedinthemachine.Use
extremecautionwhenoperatinginthese
conditions.
1515
15.1Removing the External Cover
15
The following tools are necessary to remove this component:
151515
Torx screwdriver T10 and T20
Phillips screwdriver PH2
Long nose pliers
15151515
Remove the upper cover. (* only versions M2, M2+, B2 and B2+).
151515151515
Remove the lid from the water tank.
1515151515
Remove the tank; lift it using the inside handles.
15151515
Remove the coffee bean hopper lid.
