Saeco MAGIC M2 - Turbine Disassembly; Pumps Disassembly

English
15
89
15.4Turbine Disassembly
15
The following tools are necessary to remove this component:
151515
Torx screwdriver T10
151515
To accessthe partto bereplaced, theexternal coversexplained previouslymust be
disassembled until the rear panel disassembly.
1515
Pull out the turbine by lifting it upwards.
151515151515
Disconnect the electrical connection.
151515151515
Disconnect hydraulic connections.
1515151515
If disassembly is meant for replacement it is not necessary to open the turbine.
15
Opening the turbine
15
Rotate the upper part of the turbine to open the turbine for cleaning operations.
15151515
Clean the rotating part of the turbine.
1515151515
15.5Pumps disassembly
15
The following tools are necessary to remove this component:
151515
Torx screwdriver T10
Flat-head screwdriver 0.8 x 4 x 80
Pliers for Oetiker clamps (or pair of tongs)
151515
Disassembletheexternalcoversasdescribedabove,untildisassemblyoftheleft
side, to access the component to be replaced.
15
Remove the 3 screws shown in figure using a Torx T10 screwdriver.
15151515
