15.7Removing the Gearmotor
15
The following tools are necessary to remove this component:
1515
Torx screwdriver T10
Phillips screwdriver PH2
Allen wrench no. 5
151515
Disassembletheexternalcoversasdescribedabove,untildisassemblyoftheupper
cover, toaccessthecomponenttobereplaced.Removetheboilerpinasexplained
in "Disassembling the boiler pin" section.
15
Remove the 4 screws shown in figure using a PH2 screwdriver.
15151515
Remove the gearm. and disconnect it from the power supply.
15
Remove the 4 screws shown in figure using a Torx T10 screwdriver.
15151515
Remove the CPU board.
15151515
Remove the 5 screws shown in figure using a PH2 screwdriver.
1515151515
Remove the upper cover.
1515151515
Remove the component to replace.
151515
When reassembling the entire assembly, pay attention to the following:
15
•
Gearmotor A correct position and greasing.
15
•
Greasing gears B and C.
15
•
ThepositionofgearsBandCisirrelevantgiventhattheyareautomaticallyputin
phase when the machine is switched on.
151515151515
15.8Removing the Coffee Boiler
15
The following tools are necessary to remove this component:
151515
Torx screwdriver T10 and T20
Long nose pliers
Pliers for Oetiker clamps (or pair of tongs)
151515
Disassembletheexternalcoversasdescribedabove,untildisassemblyoftheleft
side, to access the component to be replaced.
