15.18Removing the OETIKER Clamps
15
The following tools are necessary to remove this component:
151515
Pliers for Oetiker clamps (or pair of tongs)
151515
ToremovetheOETIKERclamp,cutitusingapairoftongsandreplaceitwitha
new one as shown in the figure.
1515151515
Follow the instructions shown in the figure to tighten the clamp.
1515151515
15.19Dismantling of water mains inlet solenoid valve
15
(*only
versions
M2+
and
B2+)
1515
The following tools are necessary to remove this component:
151515
Torx screwdriver T10
151515
To accessthe partto bereplaced, theexternal coversexplained previouslymust be
disassembled until the rear panel disassembly.
15
Disconnect the tube as indicated in the picture
1515151515
Carryoutthedisassemblyofthepumpsasexplainedinthesection"Pump
disassembly" until the pump unit is disassembled.
15
Remove the 2 screws shown in figure using a Torx T10 screwdriver.
15151515
