15.2Removing the coffee grinder
15
The following tools are necessary to remove this component:
151515
Torx screwdriver T10
Flat-head screwdriver 0.8 x 4 x 80
Long nose pliers
151515
Disassembletheexternalcoversasdescribedabove,untildisassemblyoftheupper
cover, to access the component to be replaced.
1515
Disconnectthecoffeegrinderwiring.Removethe2screwsshowninfigureusinga
Torx T10 screwdriver.
1515151515
Remove the grommet from the grinder adjuster lever.
1515151515
Remove the grinder adjust. lever.
1515151515
Using long nose pliers, remove the coffee grinder from its support grommets.
151515151515
Remove the coffee grinder.
1515151515151515
Grinder
disassemb.
and
replacement
1515
Turn the ring nut counter-clockwise to align the two arrows as shown in figure.
1515151515
