English
15
84
Remove the screw shown in figure using a Torx T10 screwdriver.
15
To removethisscrew,turnthescrewdriver
clockwise.
15151515
Remove the increment screw and its fasteners.
15151515
Remove the lower grinder.
1515151515
Before reassembling the coffee grinder, check that the 3 balls are on the 3 springs.
1515151515
Torefittheuppergrinderandrecalibrate
the coffee grinder, proceed as follows:
1515
1) Align the arrow on the upper grinder with the one on the coffee grinder ring nut.
1515
2) Turn the ring nut clockwise until flush (the grinders touch).
1515
3) Turn it counter-clockwise by 15 clicks.
1515
