© Safe Fleet | 2020 | All rights reserved | Part #: 700-1234 R1
DH4 Installation Guide
p. 18
DH4 Administration
SPEED DISPLAY Vehicle speed in MPH or Km/h.
VOLTAGE System voltage from 8 to 32 VDC.
TEMPERATURE DVR temperature in degrees Fahrenheit or Celsius.
TIME AND DATE Current/recorded time and date.
GPS COORDINATES If GPS is connected, the actual coordinates (latitude, longitude, and heading) appear.
If GPS is connected but the satellite signal is not being received, zeros are displayed.
AC (ALARM COUNT) Number of alarms triggered. Resets to 0 when DVR is restarted.
FAN Highlights to indicate trouble with the DVR fan.
GSN Highlights when external G-Sensor is connected.
IG Highlights when vehicle ignition is on.
