2-004
SPECIFICATIONS
SPECIFICATIONS
Performance
Vibrator
system
Front
Centrifugal force 29.0 kN ( 6,520 lbf )
Frequency 66.7 Hz ( 4,000 vpm )
Amplitude 0.31 mm ( 0.012 in. )
Rear
Centrifugal force 29.0 kN ( 6,520 lbf )
Frequency 66.7 Hz ( 4,000 vpm )
Amplitude 0.31 mm ( 0.012 in. )
Linear
pressure
Static linear
pressure
Front drum Operating weight 120 N/cm ( 70 lbf./in. )
Rear drum Operating weight 121 N/cm ( 70 lbf./in. )
Dynamic linear
pressure
Front drum Operating weight 362 N/cm ( 205 lbf./in. )
Rear drum Operating weight 363 N/cm ( 205 lbf./in. )
Traveling
speed
Number of speed shifts 2 speed
Speed range
1st
0 to 7 km/h
( 0 to 4.3 mile/h )
2nd
0 to 10 km/h
( 0 to 6.2 mile/h )
Gradeability (without vibration) 38 % ( 21 ° )
Turning
radius
Machine clearance radius inside 2.5 m ( 99 in. )
Machine clearance radius outside 3.8 m ( 150 in. )
Turning radius inside compacted surface 2.6 m ( 103 in. )
Turning radius outside compacted surface 3.7 m ( 146 in. )
Steering / Oscillating angle ± 35 ° / ± 4 °
SW354 ROPS
