Sakai TW504 - Sw354 Rops

2-003
SPECIFICATIONS
SPECIFICATIONS
1-2. SW354 ROPS
0446-99026-0-11005-0
250
1875
2455
1575
1200
1290
2675
2000
1200
67
5
675
45
540
540
540
540
Model & Type
Model SAKAI SW354 with ROPS
Type VIBRATORY TANDEM ROLLER
Weight
Operating weight
without ballast 2,960 kg ( 6,525 lbs. )
with ballast N/A kg ( N/A lbs. )
Maximum weight 3,080 kg ( 6,790 lbs. )
Shipping weight
with ROPS 2,770 kg ( 6,105 lbs. )
without ROPS 2,710 kg ( 5,795 lbs. )
Load on front axle with operating weight 1,470 kg ( 3,240 lbs. )
Load on rear axle with operating weight 1,490 kg ( 3,285 lbs. )
Dimensions
Overall length 2,675 mm ( 105 in. )
Overall width 1,290 mm ( 51 in. )
Overall height
with ROPS 2,455 mm ( 97 in. )
without ROPS 1,575 mm ( 62 in. )
Wheelbase 2,000 mm ( 79 in. )
Compaction width 1,200 mm ( 47 in. )
Front drum width × dia. × thickness 1,200 mm × 675 mm × 13 mm (47 in. × 27 in. × 0.5 in.)
Rear drum width × dia. × thickness 1,200 mm × 675 mm × 13 mm (47 in. × 27 in. × 0.5 in.)
Ground clearance 250 mm ( 10 in. )
Kerb clearance
Right 540 mm ( 21 in. )
Left 540 mm ( 21 in. )
Side clearance
Right 45 mm ( 2 in. )
Left 45 mm ( 2 in. )
Leveling blade width N/A mm ( N/A in. )
SW354 ROPS
