Sakai TW504 - Common Specifications

2-023
SPECIFICATIONS
SPECIFICATIONS
5-3. Common Specications
Engine
Model KUBOTA D1803-CR-T-EF02 (Diesel, EPA-Tier 4)
Type
4-cycle, water-cooled, 3-cylinder in-line, vertical mounted,
overhead valve, direct injection type, with turbo charger
Bore × Stroke 87.0 mm × 102.4 mm (3.425 in. × 4.031 in.)
Displacement 1.826 L ( 111.4 cu.in. )
Performance
Rated speed 2,400 min
-1
Rated output 32.3 kW ( 43 HP )
Max. torque
148 N·m ( 109 lbf·ft )
at 1,500 min
-1
Fuel consumption rate
232 g/kW·h ( 0.381 lb/HP·h )
at 2,400 min
-1
Fuel consumption 9.0 L/h with full load ( 2.4 gal. with full load)
Fuel system
Fuel Diesel (ASTM D975-2D)
Fuel injection pump High pressure common rail
Fuel injection time
regulator
Electric speed control
Lubrication
system
Lubrication type Full forced pressure feed
Oil filter type Full ow paper element
Oil cooler type Intergrated water cooled
Air intake
system
Air cleaner type Dry
Cooling
system
Cooling type Pressurized water forced circulation
Cooling fan type Inhale
Electrical
system
Alternator 12 V 60 A
Starter 12 V 2.0 kW
Battery 12 V (72 Ah, CCA 750 A) × 1 pc. (12 V)
Dry weight 200 kg (441 lbs.)
Drive system
Transmission
Type Hydrostatic
Speeds 2 speed shifts
Reverser Switching the direction of ow delivered from the variable pump
Differential
type
Front N/A
Rear N/A
Final drive
Front Direct drive
Rear Direct drive
Vibration system
Power transmission type Hydraulic
Vibrator type Single eccentric shaft
Brake system
Service brake
Dynamic braking through hydrostatic drive system
(F-N-R lever)
Secondary brake
(Emergency brake)
Hydrostatic + spring applied hydraulically released type
(Brake pedal)
Parking brake Spring applied hydraulically released type (Panel button)
Steering system
Power transmission type Hydraulic
Steering type Articulated
Drums and tyres
Use
Front Steel drum / Vibrate and drive / 1pc.
Rear Steel drum / Vibrate and drive / 1pc.
Suspension
type
Front Rubber isolation
Rear Rubber isolation
Sprinkler system
Water spray type Pressurized
Liquid spray type N/A
Others
ECO mode Standard
ROPS Option
CANOPY Option
SW504
