SPECIFICATIONS
SPECIFICATIONS
Performance
Vibrator system
Front
Centrifugal
force
Low
amplitude
26.5 kN ( 5,955 lbf )
High
amplitude
34.3 kN ( 7,710 lbf )
Frequency
Low
amplitude
55.0 Hz ( 3,300 vpm )
High
amplitude
55.0 Hz ( 3,300 vpm )
Amplitude
Low
amplitude
0.27 mm ( 0.011 in. )
High
amplitude
0.35 mm ( 0.014 in. )
Rear
Centrifugal
force
Low
amplitude
26.5 kN ( 5,955 lbf )
High
amplitude
34.3 kN ( 7,710 lbf )
Frequency
Low
amplitude
55.0 Hz ( 3,300 vpm )
High
amplitude
55.0 Hz ( 3,300 vpm )
Amplitude
Low
amplitude
0.27 mm ( 0.011 in. )
High
amplitude
0.35 mm ( 0.014 in. )
Linear
pressure
Static linear
pressure
Front drum Operating weight 150 N/cm ( 85 lbf./in. )
Rear drum Operating weight 151 N/cm ( 85 lbf./in. )
Dynamic
linear
pressure
Front drum
Operating
weight
Low
amplitude
354 N/cm ( 200 lbf./in. )
High
amplitude
414 N/cm ( 235 lbf./in. )
Rear drum
Operating
weight
Low
amplitude
355 N/cm ( 205 lbf./in. )
High
amplitude
415 N/cm ( 235 lbf./in. )
Traveling
speed
Number of speed shifts 2 speed
Speed range
1st
0 to 7.5 km/h
( 0 to 4.7 mile/h )
2nd
0 to 10 km/h
( 0 to 6.2 mile/h )
Gradeability (without vibration) 38 % ( 21 ° )
Turning
radius
Machine clearance radius inside 2.9 m ( 115 in. )
Machine clearance radius outside 4.4 m ( 174 in. )
Turning radius inside compacted surface 3.0 m ( 119 in. )
Turning radius outside compacted surface 4.3 m ( 170 in. )
Steering / Oscillating angle ± 35 ° / ± 4 °
SW504
