Sakai TW504 - Page 41

2-012
SPECIFICATIONS
SPECIFICATIONS
Performance
Vibrator system
Front
Centrifugal
force
Low
amplitude
26.5 kN ( 5,955 lbf )
High
amplitude
34.3 kN ( 7,710 lbf )
Frequency
Low
amplitude
52 Hz ( 3,100 vpm )
High
amplitude
52 Hz ( 3,100 vpm )
Amplitude
Low
amplitude
0.30 mm ( 0.012 in. )
High
amplitude
0.40 mm ( 0.016 in. )
Rear
Centrifugal
force
Low
amplitude
N/A kN ( N/A lbf )
High
amplitude
N/A kN ( N/A lbf )
Frequency
Low
amplitude
N/A Hz ( N/A vpm )
High
amplitude
N/A Hz ( N/A vpm )
Amplitude
Low
amplitude
N/A mm ( N/A in. )
High
amplitude
N/A mm ( N/A in. )
Linear
pressure
Static linear
pressure
Front drum Operating weight 149 N/cm ( 85 lbf./in. )
Rear drum Operating weight N/A N/cm ( N/A lbf./in. )
Dynamic
linear
pressure
Front drum
Operating
weight
Low
amplitude
353 N/cm ( 202 lbf./in. )
High
amplitude
413 N/cm ( 236 lbf./in. )
Rear drum
Operating
weight
Low
amplitude
N/A N/cm ( N/A lbf./in. )
High
amplitude
N/A N/cm ( N/A lbf./in. )
Traveling
speed
Number of speed shifts 2 speed
Speed range
1st
0 to 7 km/h
( 0 to 4.3 mile/h )
2nd
0 to 10 km/h
( 0 to 6.2 mile/h )
Gradeability (without vibration) 38 % ( 21 ° )
Turning
radius
Machine clearance radius inside 2.9 m ( 115 in. )
Machine clearance radius outside 4.4 m ( 174 in. )
Turning radius inside compacted surface 3.0 m ( 119 in. )
Turning radius outside compacted surface 4.3 m ( 170 in. )
Steering / Oscillating angle ± 35 ° / ± 4 °
TW504 ROPS
