Samson Trovis 6493 - Configuration List

17-2 EB 6493 EN
Annex A (conguration guide)
17.2 Conguration list
Î The functions and parameters are described in detail in the Conguration Manual uKH6493.
 …  ……………  or  ……………………………………  ………………… ……………………………  or  ……………………  and , followed by
Menu Function -CO-
Setting
options
1)
Description of functions Parameter level -PA-
Parameter
selection Parameter name Value range
1)
Control parameters
PAR
KP
TN
TV
Y.PRE
Proportional-action coefcient
Reset time
Derivative-action time
Operating point
[0.1…1.0…100.0]
[1…120…9999s]
[1…10…9999s]
[–10.0…0.0…+110.0%]
Input
IN IN1
Input signal IN1
0–20mA
4–20mA
0–10V
2–10V
100PT
1000PT
100NI
1000NI
0–1KOHM
0 to 20 mA
4 to 20 mA
0 to 10V
2 to 10V
Pt100 (–100…+500°C)
Pt1000 (–100…+500°C)
Ni100 (–60…+250°C)
Ni1000 (–60…+250°C)
0 to 1000Ω
IN1/mA
IN1/mA
IN1/V
IN1/V
IN1/PT
IN1/PT
IN1/NI
IN1/PT
IN1/KOHM
IN1
IN1
Lower measuring range value
Upper measuring range value
[–999.0…0.0…IN1]
[IN1…100.0…9999]
2)
IN2
Input signal IN2
0–20mA
4–20mA
0–10V
2–10V
100PT
1000PT
100NI
1000NI
0–1KOHM
0 to 20 mA
4 to 20 mA
0 to 10V
2 to 10V
Pt100 (–100…+500°C)
Pt1000 (–100…+500°C)
Ni100 (–60…+250°C)
Ni1000 (–60…+250°C)
0 to 1000Ω
IN2/mA
IN2/mA
IN2/V
IN2/V
IN2/PT
IN2/PT
IN2/NI
IN2/PT
IN2/KOHM
IN2
IN2
Lower measuring range value
Upper measuring range value
[–999.0…0.0…IN2]
[IN2…100.0…9999]
2)
MEAS
Signal monitoring
oFF ME.MO
IN1 ME.MO
IN2 ME.MO
ALL ME.MO
OFF
Analog input IN1
Analog input IN2
Analog inputs IN1 and IN2
noPA MEAS/ME.MO No
parameters
1)
Default setting is in bold print.
1)
Default setting is in bold print.
2)
Decimal place depends on DP function (AUX menu
