Start-up and conguration at the device
7.1.1 Conguring the compact controller
To set a function or parameter, you need to know the abbreviated code used for the function/
parameter and the menu where it can be found (see example in "Conguration and parame-
terization example" on page 7-9, AnnexA).
How to proceed:
The controller is in the operating level.
Î Open conguration level.
Reading: PAR (Control parameters menu)
If the function you want to congure is located in a different menu:
Î Select the required menu: IN, SETP, CNTR, OUT, ALRM, AUX, TUNE or I-O
Î Enter menu.
Reading: -CO- and abbreviated code of the rst function in the current menu
If you want to congure a different function:
Î Select the function you want to congure.
Î Open function.
Reading: current function setting
Î Activate editing mode for the function.
Current function setting blinks.
Every time you go to the rst function or parameter after opening the conguration level,
you are prompted to enter the key number (reading: - - - - and KEY). The key number on-
ly needs to be entered if a key number has already been assigned to the controller (see
the 'Operation' section). If this is not the case, entry of the key number can be skipped by
pressing the enter key (
).
Î Select the setting.
Î Conrm setting.
Î Change to the parameter level.
Reading: -PA-
Note
