Samson Trovis 6493 - Display

EB 6493 EN 6-3
Operation
6.3 Display
No. Operating level Congurationlevel
Depending on the level selected, the following
variables and operating states are shown on
the display
1 Controlled variable X Designations, settings and values of functions
and parameters (see the 'Design and princi-
ple of operation' section)
2 Value of W, W2, WE, Y or Xd
3 Limit relay L2 active No reading
4 Three-step output – No reading
5 Limit relay L1 active No reading
6 Three-step output + or on/off output No reading
7 Fault alarms (uKH6493 and the 'Malfunc-
tions' section)
No reading
8 Hand icon displayed in manual mode, no
icon in automatic mode
No reading
9
Press
key to display W, W2, WE, Y or
Xd% in sequence. The associated value ap-
pears in (2). W2 and WE only when they
have been congured (uKH6493).
Fast access to parameters:
Each time the
key is pressed, the decimal
point of the parameter is shifted one place to
the right.
10 Bar reading of Xd in %
