Samson Trovis 6493 - Values for Resistance Thermometers

EB 6493 EN 3-9
Design and principle of operation
3.3 Values for resistance thermometers
Pt100sensors(accordingtoDINEN60751:2009-05)
Temperature°C –100 –90 –80 –70 –60 –50 –40 –30 –20 –10 0
Resistance Ω 60.26 64.30 68.33 72.33 76.33 80.31 84.27 88.22 92.16 95.09 100.00
Temperature°C +10 +20 +30 +40 +50 +60 +70 +80 +90 +100 +110
Resistance Ω 103.90 107.79 111.67 115.54 119.40 123.24 127.08 130.90 134.71 138.51 142.29
Temperature°C +120 +130 +140 +150 +160 +170 +180 +190 +200 +210 +220
Resistance Ω 146.07 149.83 153.58 157.33 161.05 164.77 168.48 172.17 175.86 179.53 183.19
Temperature°C +230 +240 +250 +260 +270 +280 +290 +300 +310 +320 +330
Resistance Ω 156.84 190.47 194.10 197.71 201.31 209.90 208.48 212.05 215.61 219.15 222.68
Temperature°C +340 +350 +360 +370 +380 +390 +400 +410 +420 +430 +440
Resistance Ω 226.21 229.72 233.21 236.70 240.18 243.64 247.09 250.53 253.96 257.38 260.78
Temperature°C +450 +460 +470 +480 +490 +500
Resistance Ω 264.18 267.56 270.93 274.29 277.64 280.98
Pt1000sensors
Multiply the corresponding resistance values in the 'Pt100 sensors' table by 10.
Ni100sensors(accordingtoDIN43760:1987-09)
Temperature°C –60 –50 –40 –30 –20 –10 0 +10 +20 +30 +40
Resistance Ω 69.5 74.3 79.1 84.1 89.3 94.6 100.0 105.6 111.2 117.1 123.0
Temperature°C +50 +60 +70 +80 +90 +100 +110 +120 +130 +140 +150
Resistance Ω 129.1 135.3 141.7 148.3 154.9 161.8 168.8 176.0 183.3 190.9 198.6
Temperature°C +160 +170 +180 +190 +200 +210 +220 +230 +240 +250
Resistance Ω 206.6 214.8 223.2 231.8 240.7 249.8 259.2 268.9 278.9 289.2
Ni1000sensors
Multiply the corresponding resistance values in the 'Ni100 sensors' table by 10.
