Start-up and conguration with TROVIS-VIEW
The 'Reset to default settings' function in the AUX folder causes all parameters, functions and
calibration data to be reset to their default settings.
The System data (1) and (2) saved in the controller are not cleared.
8.2.3.8 Start-up adaptation [TUNE]
The Start-up adaptation [TUNE] folder corresponds to the TUNE main group of the controller.
It is possible to preset a start-up adaptation to automatically tune the control parameters KP,
TN and TV in this folder. In addition, the start-up adaptation can be started or canceled.
The conditions for performing an adaptation are listed in the 'Start-up and conguration at
the device' section.
Starting the adaptation
1. Open the 'Operation' folder.
2. Set manual mode:
Î Set 'Manual/automatic switch' to 'Manual' and transfer the new setting to the controller.
3. Determine the set point and transfer it to the controller.
4. In manual mode, set the controlled variable to match the set point.
5. Open the 'Start-up adaptation [TUNE]' folder.
6. Enter the step response in 'Step-change value of manipulated variable [Y.JMP]' eld and
transfer it to the controller.
7. Set 'Start-up adaptation' to 'Start'.
8. Right-click 'Start-up adaptation' and select 'Execute' from the context-sensitive menu.
Adaptation is started.
Exiting or canceling the adaptation
1. Open the 'Start-up adaptation [TUNE]' folder.
2. Set 'Start-up adaptation' to 'Off'.
3. Right-click 'Start-up adaptation' and select 'Execute' from the context-sensitive menu. Ad-
aptation is ended.
In online mode, the adaptation progress is displayed in 'Adaptation status'.
