EB 6493 EN 17-5
Annex A (conguration guide)
 …  ……………  or  ……………………………………  ………………… ……………………………  or  ……………………  and , followed by
Menu Function -CO-
Setting
options
1)
Description of functions Parameter level -PA-
Parameter
selection Parameter name Value range
1)
IN MAN
Switch to manual
mode in case of
signal failure
off FAIL OFF
F01 FAIL
F02 FAIL
With constant output value Y1K1
With last manipulated variable value
MAN/FAIL
Y1K1 Constant output value [–10.0…+110%]
CLAS
Assignment of X to
analog inputs
In2 X
In1 X
X = IN2
X = IN1
noPA CLAS/X No
parameters
Assignment of WE to
analog inputs
In1 WE
In2 WE
WE = IN1
WE = IN2
noPA CLAS/WE No
parameters
DI.FI
Filtering input
variable X
oFF X
on X
OFF
ON DI.FI/X TS.X Time constant X lter [0.1…1.0…100.0s]
Filtering input
variable WE
oFF WE
on WE
OFF
ON DI.FI/WE TS.WE Time constant WE lter [0.1…1.0…100.0s]
SQR
Root extraction input
variable X
oFF X
on X
OFF
ON
noPA SQR/X No
parameters
Root extraction input
variable WE
oFF WE
on WE
OFF
ON
noPA SQR/WE No
parameters
FUNC
Function generation
input variable X
oFF X OFF MIN Lower output signal measuring range value [–999.0…0.0…MAX]
2)
on X ON FUNC/X MAX
K1.X
K1.Y
…
K7.X
K7.Y
Upper output signal measuring range value
Input value 1
Output value 1
…
Input value 7
Output value 7
[MIN…100.0…9999]
2)
[IN1…IN1], [IN2…IN2]
[MIN…MAX]
…
[IN1…IN1], [IN2…IN2]
[MIN…MAX]
Function generation
input variable WE
oFF WE OFF MIN Lower output signal measuring range value [–999.0…0.0…MAX]
2)
on WE ON FUNC/WE MAX
K1.X
K1.Y
…
K7.X
K7.Y
Upper output signal measuring range value
Input value 1
Output value 1
…
Input value 7
Output value 7
[MIN…100.0…9999]
2)
[IN1…IN1], [IN2…IN2]
[MIN…MAX]
…
[IN1…IN1], [IN2…IN2]
[MIN…MAX]
1)
Default setting is in bold print.
1)
Default setting is in bold print.
2)
Decimal place depends on DP function (AUX menu
