17-14 EB 6493 EN
Annex A (conguration guide)
 …  ……………  or  ……………………………………  ………………… ……………………………  or  ……………………  and , followed by
Menu Function -CO-
Setting
options
1)
Description of functions Parameter level -PA-
Parameter
selection Parameter name Value range
1)
Limit relay
ALRM LIM1
Limit relay L1
oFF L1
Lo L1.X
Hi L1.X
Lo L1.WE
Hi L1.WE
Lo L1.YP
Hi L1.YP
Lo L1.XD
Hi L1.XD
AbS L1.XD
OFF
When X is not reached
When X is exceeded
When WE is not reached
When WE is exceeded
When YPID is not reached
When YPID is exceeded
When XD is not reached
When XD is exceeded
When absolute value of XD is
exceeded
LIM1/L1.X
LIM1/L1.X
LIM1/L1.WE
LIM1/L1.WE
LIM1/L1.YP
LIM1/L1.YP
LIM1/L1.XD
LIM1/L1.XD
LIM1/L1.XD
LI.X Limit for X
[IN1…100.0…IN1]
23
[IN2…100.0…IN2]
23
LI.WE Limit for WE
[IN1…100.0…IN1]
23
[IN2…100.0…IN2]
23
LI.YP
LI.XD
LI.HYS
Limit for YPID
Limit for XD
Hysteresis
[Y…100.0%…Y]
[–110.0…0.0…+110.0%]
[0.10…0.50…100.0%]
LIM2
Limit relay L2
oFF L2
Lo L2.X
Hi L2.X
Lo L2.WE
Hi L2.WE
Lo L2.YP
Hi L2.YP
Lo L2.XD
Hi L2.XD
AbS L2.XD
OFF
When X is not reached
When X is exceeded
When WE is not reached
When WE is exceeded
When YPID is not reached
When YPID is exceeded
When XD is not reached
When XD is exceeded
When absolute value of XD is
exceeded
LIM2/L2.X
LIM2/L2.X
LIM2/L2.WE
LIM2/L2.WE
LIM2/L2.YP
LIM2/L2.YP
LIM2/L2.XD
LIM2/L2.XD
LIM2/L2.XD
LI.X Limit for X
[IN1…100.0…IN1]
23
[IN2…100.0…IN2]
23
LI.WE Limit for WE
[IN1…100.0…IN1]
23
[IN2…100.0…IN2]
23
LI.YP
LI.XD
LI.HYS
Limit for YPID
Limit for XD
Hysteresis
[Y…100.0%…Y]
[–110.0…0.0…+110.0%]
[0.10…0.50…100.0%]
1)
Default setting is in bold print.
1)
Default setting is in bold print.
2)
Decimal place depends on DP function (AUX menu
3)
Value range identical to that of assigned input
