17-18 EB 6493 EN
Annex A (conguration guide)
 …  ……………  or  ……………………………………  ………………… ……………………………  or  ……………………  and , followed by
Menu Function -CO-
Setting
options
1)
Description of functions Parameter level -PA-
Parameter
selection Parameter name Value range
1)
Start-up adaptation
TUNE ADAP
Adaptation
oFF ADP.S
run ADP.S
OFF
Start
KP
TN
TV
Y.JMP
Proportional-action coefcient
Reset time
Derivative-action time
Step-change value for adaptation
[0.1…1.0…100.0]
[1…120…9999s]
[1…10…9999s]
[–100.0…+20.0…+100.0%]
ADAP/ADP.S
Process data
I-O CIN
Firmware version
Reading
S-No
Serial number
Reading
ANA
Show analog inputs
and outputs
IN1
IN2
CO.VA
WE.VA
FE.CO
SP.CO
YPID
YOUT
Analog input IN1
Analog input IN2
Controlled variable before function
generation
WE before function generation
WE after function generation
Set point at comparator
YPID after limitation
Analog output
BIN
Show binary inputs
and outputs
BI1
BO1
BO2
Binary input BI
Binary output BO1
Binary output BO2
ADJ
Calibration
AdJ IN1
AdJ IN2
AdJ YOUT
Analog input IN1
Analog input IN2
Analog output
1)
Default setting is in bold print.
1)
Default setting is in bold print.
