8-2 EB 6493 EN
Start-up and conguration with TROVIS-VIEW
Connecting the infrared adapter
1. Connect the infrared adapter to the computer using the USB to RS-232 adapter.
2. Install the driver for USB to RS-232 adapter.
An IrDA driver will impair the functioning of TROVIS-VIEW.
An IrDA driver must not be installed on the computer on which TROVIS-VIEW is installed.
Otherwise, TROVIS-VIEW will not run properly.
Î If such a driver is installed, deactivate the IR device in Windows
®
Control Panel or assign
a different COM port.
The driver can be downloaded from our website uwww.samsongroup.com > SERVICE &
SUPPORT > Download > TROVIS-VIEW.
3. Start TROVIS-VIEW with device module TROVIS6493.
4. Select 'Communication...' from the 'Options' menu. Click 'Connection settings' buttons
and select the COM port.
To ensure data transmission functions properly without the use of a bracket, place the infra-
red adapter so that the distance to the infrared interface does not exceed 0.7m and that the
max. angle 25° is kept (see Fig.8-1). Make sure the transmission path is not obstructed.
We recommend using the infrared adapter with the corresponding bracket (see Fig.8-1).
NOTICE
!
Note
Note
Tip
