Operation
Calibratinganaloginputs:
1. Connect a high-precision meter at the input (IN1, IN2).
2. In the I-O menu, select the ADJ function.
3. Use the cursor keys (
, ) to select the input you want to calibrate (AdJ IN1, AdJ IN2).
4. Conrm the input (
).
You are prompted to enter the key number.
5. Enter the key number or continue by pressing .
6. Use the high-precision meter to set the input signal to the required lower range value.
Alternating reading: ZERO and IN1 (IN2)
7. Conrm lower range value (
).
Reading: 0.0 and ZERO
8. Use the high-precision meter to set the input signal to the required upper range value.
Alternating reading: SPAN and IN1 (IN2)
9. Conrm upper range value ( ).
Reading: 100.0 and SPAN
Calibratinganalogoutputs:
1. Connect a high-precision meter at the analog output (Y).
2. In the I-O menu, select the ADJ function.
3. Use the cursor keys (
, ) to select the output (AdJ YOUT).
4. Conrm the output (
).
You are prompted to enter the key number.
5. Enter the key number or continue by pressing .
6. Use the cursor keys (
, ) to set the output so that the lower range value is indicated
on the high-precision meter.
Alternating reading: ZERO and YOUT
7. Conrm lower range value (
).
Reading: 0.0 and ZERO
8. Use the cursor keys ( , ) to set the output so that the upper range value is indicated
on the high-precision meter.
Alternating reading: SPAN and YOUT
9. Conrm upper range value (
).
Reading: 100.0 and SPAN
