1.4.2 TERMINAL WIRING DIAGRAM
1.4.2.1 TEMP880S Mainframe Terminal
STANDARD : TEMP880S-10(RS232C + I/O1) OPTION1 : TEMP880S-11(RS485 + I/O1)
Add UDC option : TEMP880S-10/UDC Add UDC Option : TEMP880S-11/UDC
OPTION2 : TEMP880S-20(RS232C + I/O1 + I/O2) OPTION3 : TEMP880S-21(RS485 + I/O1 + 1/O2)
Add UDC Option : TEMP880S-20/UDC Add UDC Option : TEMP880S-21/UDC
RS232C
RS485
RTX+
I
/
O2 LINK
I
/
O2 LINK
RS485
RTX-
SG
RS232C
RS485
RTX+
RS485
RTX-
SG
