1st Edition of TEMP880S IM : Sep. 21. 2005 Page 11 / 101
1.4.2.2 I/O1 RELAY BOARD TERMINAL
1.4.2.3 I/O2 RELAY BOARD TERMINAL
COM4
I/O2
LINK
I/O2 BOARD
GND +24V
RLY20 RLY19 COM3 RLY18 RLY17 COM2 RLY16 RLY15 RLY14 COM1 RLY13 RLY12 RLY11
RLY7_NC RLY7_NO COM4 RLY8_NO RLY8_NC RLY9_NC RLY9_NO COM5 RLY10_NO RLY10_NC
External
connecting
switch RLY 10
→ It operates
by being
connected to
“
AND
”
P10
AOUT1- AOUT1+
Temperature(heatin
g) control output
AOUT2- AOUT2+
Freezing control
output
RET1- RET1+
Transmission
output 1
RET2- RET2+
Transmission
output 2
RLY6
COM3
RLY5
RLY4
COM2
RLY3
RLY2
COM1
RLY1
+24V GND
DI_COM DI8 DI6 DI4 DI2
DI_COM DI7 DI5 DI3 DI1
I/O1
LINK
L N FG
220V AC
I/O1 BOARD
