SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 74 / 101
2.10 Pattern Setting
Symbol Parameter Setting Range Unit Initial Value
PTN NO PATTERN NUMBER 1~120 ABS 1
CYCLE CYCLE SET 1~9999 ABS 1
END END MODE SET
RESET(STOP),
HOLD(LAST TSP)
ABS RESET
PTN NAME 1~120 PATTERN NAME 1~120
0~9, A~Z, Sepcial
Character
(Max. 10 Characters)
ABS
PROG PT001
~ PROG PT120
TSP
SEGMENT(ZONE)
TEMP TSP
EU(0~100%) EU EU(0%)
TIME
SEGMENT(ZONE)
TIME
0.01~99.59 (HOUR.MIN) ABS 00.01
WAIT SP WAIT SP EU(0~100%) EU EU(0%)
TS1~TS3 TIME SIGNAL1~3 0 ~ 7 ABS 0
SRC. PTNO
SOURCE PATTERN
NUMBER
1~120 ABS 0
DES. PTNO
DESTINATION PATTERN
NUMBER
1~120 ABS 0
DEL. PTNO
DELETE PATTERN
NUMBER
1~120 ABS 0
2.11 Screen Selection
Symbol Parameter Setting Range Unit Initial Value
TUNING KEY
TUNING KEY DISPLAY
BUTTON
DISP, HIDE ABS DISP
LIGHT OFF LIGHT OFF 0~99 ABS 10
CONTRAST SET CONTRAST GROUP SET 8 LEVEL ABS 4 LEVEL
2.12.1.1 Input Setting
Symbol Parameter Setting Range Unit Initial Value
SENSOR SENSOR SET
TC-K1, TC-K2, TC-J,
TC-J, TC-E, TC-T,
TC-R, TC-B, TC-S,
TC-L, TC-N, TC-U
TC-W, TC-PA
ABS TC-T
UNIT SENSOR UNIT ℃, ℉ ABS ℃
TEMP RANGE HIGH EU EU(100%)
TEMP RANGE
TEMP RANGE LOW
EU(0~100%)
TEMP RL < TEMP RH
EU EU(0%)
TC.SEL TC SELECT TC, T+R, RTC ABS T+R
B.OUT BURN OUT OFF, UP, DOWN ABS UP
BIAS ALL BIAS EUS(-105~105%) EUS EUS(0%)
FILTER FILTER TIME 0~120 SEC ABS 0
TEMP SP HIGH EU EU(100%)
H.TEMP SP
N.TEMP SP
L.TEMP SP
TEMP SP LOW
EU(0~100%)
SP.RL < SP.RH
EU EU(0%)
DEFROST SP HIGH EU 100.0
DEFROST SP
DEFROST SP LOW
EU(0~100%)
SP.RL < SP.RH
EU -10.0
To Next Page
