Samwon Tech TEMP880S User Manual

SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 75 / 101
2.12.1.2 Sector Input Revision Setting
Symbol Parameter Setting Range Unit Initial Value
POINT1.DDV
POINT2.DDV
POINT3.DDV
POINT4.DDV
POINT5.DDV
POINT6.DDV
POINT7.DDV
POINT8.DDV
DIFFERENCE VALUE1~8 EUS(-10~10%) EUS EUS(0%)
POINT1.DPV REFERENCE POINT1 EU EU(0%)
POINT2.DPV REFERENCE POINT2
POINT3.DPV REFERENCE POINT3
POINT4.DPV REFERENCE POINT4
POINT5.DPV REFERENCE POINT5
POINT6.DPV REFERENCE POINT6
POINT7.DPV REFERENCE POINT7
POINT8.DPV REFERENCE POINT8
EU(0~100%)
RL≤ POINT1.DPV
≤ POINT2.DPV
≤ POINT3.DPV
≤ POINT4.DPV
≤ POINT5.DPV
≤ POINT6.DPV
≤ POINT7.DPV
≤ POINT8.DPV ≤RH
EU EU(100%)
2.12.2 Control Output and Transmission Setting
Symbol Parameter Setting Range Unit Initial Value
TYPE
COMMON OUTPUT
TYPE
SSR, SCR ABS SSR
DIRECT
COMMON OUTPUT
DIRECTION
REV, FWD ABS REV
CYCLE
COMMON OUTPUT
CYCLE TIME
1~300 SEC ABS 1
P.OUT PRESET OUTPUT -5.0~105.0% % 0.0%
ARW ANTI RESET WINDUP 0.0(AUTO), 0.1~200.0 % 100.0
WSP.DEV WAIT SP DEVIATION EUS(10%) EUS EUS(0.0%)
RET1 SELECT
RET2 SELECT
RETRANSMISSION
SELECT
RTP.PV, HTP.PV,
LTP.PV
ABS
RET1(RTP.PV)
RET2(RTP.PV)
RET1. RANGE
RET2. RANGE
RETRANSMISSION
RANGE HIGH
EU(0~100%)
RET RL < RET RH
EU EU(100%)
2.12.3 Inner Signal
Symbol Parameter Setting Range Unit Initial Value
RANGE-L
INNER SIGNAL RANGE
LOW
EU EU(0%)
RANGE-H
INNER SIGNAL RANGE
HIGH
EU(0~100%)
RANGE-L ≤ RANGE-H
EU EU(0%)
TIME
INNER SIGNAL DELAY
TIME
00.00~99.59
(HOUR.MIN)
ABS 00.00
TYPE INNER SIGNAL TYPE SP, PV ABS SP
BAND
INNER SIGNAL BAND
DIRECT
INB, OUTB ABS INB
