2.12.4 PID Setting
Symbol Parameter Setting Range Unit Initial Value
RP1 REFERENCE POINT1
RP2 REFERENCE POINT2
RL≤RP1≤RP2≤RH EU EU(100%)
H.RDV REFERENCE DEVIATION EUS(0.0~100.0%) EUS EUS(0.0%)
L.RDV REFERENCE DEVIATION EUS(0.0~100.0%) EUS EUS(0.0%)
RHY
REFERENCE
HYSTERESIS
EUS(0.0~100.0%) EUS EUS(0.3%)
H.TEMP PID NO H.TEMP PID NO 1,2,3,4 ABS 1
L.TEMP PID NO L.TEMP PID NO 1,2,3,4 ABS 1
CONTROL MODE CONTROL MODE D.DV, D.PV ABS D.PV
P(1~4) PROPORTIONAL BAND 0.1~999.9% ABS 5.0%
I(1~4) INTEGRAL TIME 0~6000S ABS 120S
D(1~4) DERIVATIVE TIME 0~6000S ABS 30S
OH(1~4) OUTPUT LIMIT HIGH ABS 100.0
OL(1~4) OUTPUT LIMIT LOW
0.0~100.0
OL < OH
ABS 0.0
