Samwon Tech TEMP880S User Manual

SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 77 / 101
2.12.5 DO CONFIG Setting
Symbol Parameter Setting Range Unit Initial Value
IS1~IS8 RELAY
INNER SIGNAL1~8
RELAY
0(OFF)~20 ABS 0
TS1~TS3 RELAY
TIME SIGNAL1~3
RELAY
0(OFF)~20 ABS 0
DFR RELAY DEFROST RELAY 0(OFF)~20 ABS 0
AL1~AL4 RELAY
ALARM SIGNAL1~4
RELAY
0(OFF)~20 ABS 0
DI5~DI8 RELAY
DI SIGNAL5~8
RELAY
0(OFF)~20 ABS 0
DI5~DI8 OUTPUT
DI SIGNAL5~8
OUTPUT TYPE
FWD, REV ABS FWD
DI5~DI8 MODE
DI SIGNAL5~8
ERROR MODE
STOP, RUN ABS STOP
RUN RELAY RUN RELAY 0(OFF)~20 ABS 0
RUN CPARA RUN DELAY TIME 0~999 SEC ABS 0
END RELAY END SIGNAL RELAY 0(OFF)~20 ABS 0
END CPARA END SIGNAL TIME 0~999 SEC ABS 0
HD.ON RELAY
RD.ON RELAY
LD.ON RELAY
ZONE DAMPER ON
SIGNAL RELAY
0(OFF)~20 ABS 0
HD.ON CPARA
RD.ON CPARA
LD.ON CPARA
ZONE DAMPER ON
SIGNAL TIME
0~999 SEC ABS 0
HD.OFF RELAY
RD.OFF RELAY
LD.OFF RELAY
ZONE DAMPER OFF
SIGNAL RELAY
0(OFF)~20 ABS 0
HD.OFF CPARA
RD.OFF CPARA
LD.OFF CPARA
ZONE DAMPER OFF
SIGNAL TIME
0~999 SEC ABS 0
ERROR RELAY ERROR RELAY 0(OFF)~20 ABS 0
ERROR CPARA ERROR SIGNAL TIME 0~999 MIN ABS 0
SOL RELAY SOL RELAY 0(OFF)~20 ABS 0
SOL CPARA SOL SIGNAL TIME EU(0~100%) EU EU(0%)
1REF RELAY
FIRST REFRIGERATION
SIGNAL RELAY
0(OFF)~20 ABS 0
1REF CPARA
FIRST REFRIGERATION
SIGNAL TIME
0~999 SEC ABS 0
2REF RELAY
SECOND
REFRIGERATION
SIGNAL RELAY
0(OFF)~20 ABS 0
2REF CPARA
SECOND
REFRIGERATION
SIGNAL TIME
0~999 MIN ABS 0
H.FAN RELAY
R.FAN RELAY
L.FAN RELAY
HIGH FAN RELAY
ROOM FAN RELAY
LOW FAN RELAY
0(OFF)~20 ABS 0
N2GAS RELAY N2GAS SIGNAL RELAY 0(OFF)~20 ABS 0
N2GAS CPARA N2GAS SIGNAL CPARA 0~999 SEC ABS 0
