Samwon Tech TEMP880S User Manual

SAMWONTECH
1st Edition of TEMP880S IM : Sep. 21. 2005 Page 78 / 101
2.12.6 Alarm and DI Error Name Setting
Symbol Parameter Setting Range Unit Initial Value
TYPE ALARM TYPE
AH.F, AL.F, DH.F
DL.F, DH.R, DL.R
DO.F, DI.F, AH.R
AL.R, AH.FS, AL.FS
DH.FS, DL.FS, DH.FS
DL.RS, DO.FS, DI.FS
AH.RS, AL.RS
ABS
ALARM1,3
→ AH.F
ALARM2,4
→ AL.F
POINT ALARM POINT EU(-105~105%) EU EU(100%)
HYS ALARM HYSTERESIS EUS(0~100%) EUS EUS(0.5%)
BUZZER TIME BUZZER TIME 0~99 MIN ABS 1
DI2~DI8 NAME DI2~DI8 NAME
0~9, A~Z, Special
Character
(Max. 9 Characters)
ABS
DI2:ERR HTEMP
DI3:ERR NTEMP
DI4:ERR LTEMP
DI5:OVR 1.REF
DI6:OVR 2.REF
DI7:OVR 1.MOT
DI8:OVR 2.MOT
2.12.7 Communication Setting
Symbol Parameter Setting Range Unit Initial Value
PROTOCOL PROTOCOL
PCL0
(PC LINK)
PCL1(PC LINK with SUM
CHECK)
MODA(MODBUS ASCII),
MODR(MODBUS RTU),
SYNM(SYNC MASTER)
ABS PCL1
BPS BIT PER SEC
600, 1200, 2400,
4800, 9600
ABS 9600
STOP BIT STOP BIT 1, 2 ABS 1
PARITY PARITY NONE, EVEN, ODD ABS NONE
D.LENGTH DATA LENGTH 7, 8 ABS 8
ADDRESS ADDRESS
1 ~99
(however,Max.99 Sets)
ABS 1
RESPONSE RESPONSE TIME 0~10 ABS 0
2.12.8 Initial Display Setting
Symbol Parameter Setting Range Unit Initial Value
PASSWORD PASSWORD SET 0~9999 ABS 0
LANGUAGE SET LANGUAGE SET ENG, CHN ABS ENG
INFO1 COMPANY INFORMATION
0~9, A~Z, Special
Character
(Max. 9 Characters)
ABS
SAMWONTECH
CO.,LTD
INFO2
TELEPHONE
INFORMATION
0~9, A~Z, Special
Character
(Max. 9 Characters)
ABS
TEL: 82-32-326-
9120
INFO3
HOMEPAGE
INFORMATION
0~9, A~Z, Special
Character
(Max. 9 Characters)
ABS
WWW.SAMWONTECH.
COM
