4.3.7 WRD Command
▶ WRD Command is used for using the Random data of D-Register.
▶ Format of Transmission
The number
of Byte
1 2 3 1 2 1 4 1 4 1 …
S
T
Contents
X
Addr WRD , Number , D-Reg. No1 , dddd-1 , …
1 4 1 4 2 1 1
C L
, D-Reg. No(n) , dddd-(n) SUM
R F
▶ Response
The number
of Byte
1 2 3 1 2 2 1 1
S
T
Contents
X
Addr WRD , OK SUM
C
R
L
F
- The number of (~) : 1~32
- dddd F : Data without a point of decimal number (16 number D)
ex) In case of using data to Outage Mode(D0105) and Outage Time(D0125)
- Transmission : [stx] 01RRD,02,0001,0002[cr][lf]
- Transmission (Including Check Sum) : [stx]01WRD,02,0105,0001,0125,00039E[cr][lf]
